Hydraulic Laboratory
Hydraulic laboratory is equipped with different hydraulic instruments which are used for performic different test in hydraulic and hydrodynamics. There are open channel flume testers for simulating water flow, instruments for hydrostatic testing, Renault tester, Bernoulli equation tester, pilot tube, local resistance tester, and other.
Flume
Features and Applications:
This water flume is an open channel. It is used for hydraulics and fluid flow tests.
Hydraulics Demonstration Instrument
Features and Applications:
Open channel flume tester which is used to observe weir
flow and water jump phenomena.
Hydraulics Demonstration Instrument
Features and Applications:
This is a flow demonstrator. It is used to demonstrate the stream – line and trajectory of wing flow and lift direction.
Hydraulics Demonstration Instrument
Features and Applications:
Bernoulli equation tester is applied to measure the changes in fluid pressure when the water flow velocity changes.
Hydraulics Demonstration Instrument
Features and Applications:
Renault tester is used to demonstrate changes in flow
direction at different flow velocities.
Hydraulics Demonstration Instrument
Features and Applications:
Water hammer comprehensive experimental instrument is for observation of phenomena such as water
hammer wave propagation, water hammer lifting,
and pressure regulating cylinder reduction of water
hammer.
